- Dry Core Bit (LA)
- YOUR POSITION:HOME > Products > Diamond Drilling > Dry Core Bit (LA) > Views
Premium Grade
Segment Type: Turbo
Series: LA Premium Grade (LPG)
|
Dia.（mm) |
Dia.（Inch) |
Drill depth (mm) |
Total length (mm) |
Thread |
Seg.Size (mm) |
Segs.No. |
|
Φ32 |
1-1/4" |
150 |
170 |
G 1/2" |
16x3.7x10 |
3 |
|
Φ38 |
1-1/2" |
150 |
170 |
G 1/2" |
16x3.7x10 |
3 |
|
Φ51 |
2" |
150 |
170 |
G 1/2" |
16x3.7x10 |
4 |
|
Φ63 |
2-1/2" |
150 |
170 |
G 1/2" |
24x3.7x10 |
4 |
|
Φ76 |
3" |
150 |
170 |
G 1/2" |
24x3.7x10 |
4 |
|
Φ102 |
4" |
150 |
170 |
G 1/2" |
24x3.7x10 |
5 |
|
Φ127 |
5" |
150 |
170 |
G 1/2" |
24x3.7x10 |
5 |
|
Φ152 |
6" |
150 |
170 |
G 1/2" |
24x4.0x10 |
7 |
|
Φ180 |
7" |
150 |
170 |
G 1/2" |
24x4.5x10 |
9 |
|
Φ200 |
8" |
150 |
170 |
G 1/2" |
24x4.5x10 |
9 |
* The centering device is available upon request, M16/M22 to SDS-Plus or SDS-Max.
Feature:
1) Special bond formula, supreme diamond crystals, vacuum
hot press sintered.
2) Laser welded technology ensures no loss of segments.
3) Excellent drilling speed and long extension meter.
Application:
1) Suit for drilling brick wall, normal or special
concrete with light steel rebar inside.
2) Used on hand held core drill or rotary
hammer.
